Cummins QSM11-G2 Diesel Engine for Generator Set
General data of Cummins QSM11-G2 Diesel Engine for Generator Set |
Engine Model |
Cummins QSM11-G2 |
Type |
6 Cylinder, In-line, 4 Stroke |
Displacement |
10.8 L |
Bore&Stroke |
125*147 mm |
Dry Weight(with flywheel and alternator) |
973 KG |
Wet Weight(with flywheel and alternator) |
1007 KG |
|
Performance Date of Cummins QSM11-G2 Diesel Engine for Generator Set |
Rated Output/Speed |
292KW/1500RPM |
Standby Output/Speed |
321KW/1500RPM |
Rated Output/Speed |
427W/1800RPM |
Standby Output/Speed |
470KW/1800RPM |
Fuel Consumption/Rated Output |
69 L/h |
Fuel Consumption/Standby output |
79 L/h |
|
Technical data of Cummins QSM11-G2 Diesel Engine for Generator Set |
Aspiration |
Turbocharged, Air-Air Intercooled |
Fuel System |
PT Pump Direct Injection |
Emission Standard |
EU Stage II |
Engine Cooling Fluid Volume |
34 L |
Coolant Capacity, Engine Only |
9.5 L |
Idle speed |
675-750 RPM |
Maximum Friction Power |
22.4 KW |
Compression Ratio |
16.3:1 |
Firing Order |
1-5-3-6-2-4 |
The above is general technical specification of Cummins QSM11-G2 diesel engine for generator set. It is also for us to supply the Cummins QSM11-G2 genuine engine parts and Cummins diesel generator set of this engine.
